    SICC Cone Seal Inline Electromagnetic Flow Meters 0.2 High Accuracy

    Ask Lasest Price
    Brand Name : CHONGQING CHUANYI, SICC
    Model Number : MF
    Certification : IECEX certification, CE certification, CU-TR(ERC) certification, CCS certification ,ISO9001, ISO14000, ISO45001
    Price : Negotiated Pricing
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : As Appropriate
    Delivery Time : As Appropriate
    • Product Details
    • Company Profile

    SICC Cone Seal Inline Electromagnetic Flow Meters 0.2 High Accuracy

    MULTIPHASE FLOW CONE SEAL MF ELECTROMAGNETIC FLOWMETER

    • The flow measurement range is wide, and the range ratio is 1500:1.
    • The flow rate of minimum guaranteed accuracy is 0.2m/s.
    • Advanced sensor technology can ensure that the installation of straight pipe section takes only 1.6D.
    • High accuracy: up to 0.2% indicating value
    • Forward and backward flow are measurable: pulse flow, multiphase flow and slurry are measurable.
    • The input of the converter is more than 1012 ohms, which can effectively prevent the influence of scaling on the sensor, and the minimum conductivity can reach 1.7us/cm.
    • The electrode seal adopts a unique double-sided sealing method of cone seal and line seal.
    • Buried installation and long-term immersion installation are allowable, up to IP68.
    • Multi-frequency excitation technology/DSP digital processing technology/high frequency sampling technology/data coordinating analysis technology
    • Self-diagnosis (excitation circuit/empty pipe detection/upper and lower limits/system storage)

    Main Technical Parameters:


    Flow Master

    MFP Plug in type

    electromagnetic flowmeter

    One typesplit type
    Basic error± 0.5% ~ ± 1.0% (Under reference conditions)
    caliber (mm)DN200~DN3000DN200~DN3000
    flangeComply with GB9119 standard, stainless steel
    Pressure class1.6MPa
    Converter housing materialDie cast aluminum alloy
    Sensor housing materialstainless steel
    Sensor structure and materialstainless steel/PVDF
    conductivity≥5μS/CM(Less than ≥ 5 μ S / cm negotiates the order with our company )
    electrode316L, Hastelloy, titanium, tantalum, platinum iridium alloy, tungsten carbide
    Degree of protectionIP65/IP67IP65/IP67(Sensor optional IP68)
    Medium temperature-25℃~80℃-25℃~120℃
    ambient temperature-25℃~60℃
    Influence of ambient temperature<±0.1%/10℃or<±0.25%/10℃
    Repeatability and repeatability≤±0.1%or±0.25%
    Analog output error≤±0.02mA
    Measuring range flow rate0.3m/s≤V≤10m/s
    Embedability------------≤5m(Only IP68)
    Electrical connectionM20*1.5Sealing sleeve,G1/2,NPT1/2
    Sensing cable------------

    <30m

    If it is too long, you need to negotiate with our company to order


    Application Scenarios:
